Napoleon Allure Series User Manual

W415-1699 / 02.08.16
EN
4
table of contents
1.0 general information 5
1.1 dimensions 5
1.2 product information 5
1.3 general instructions 6
1.4 unpacking and testing appliance 6
1.5 hardware parts list 7
1.6 rating plate information 8
1.7 locating appliance 8
2.1 minimum clearance to combustibles 9
2.0 installation 9
2.2 minimum mantel clearances 10
2.3 framing 11
2.4 installing the appliance 12
2.5 recessing the appliance into the wall 13
2.6 installing the appliance into a mantel 14
2.7 rubber feet installation 15
2.8 hard wiring installation 16
3.1 front glass installation 17
3.0 finishing 17
3.2 front glass removal 18
3.3 crystal ember installation 18
4.1 main power button 19
4.2 operating touch display panel and remote control 19
4.0 operating instructions 19
5.0 maintenance 20
5.1 remote battery installation 20
6.0 wiring diagram 21
7.0 replacement parts 23
8.0 troubleshooting 25
9.0 warranty 26
10.0 service warranty 27
The camera icon indicates video tutorials are available as additional reference, visit
http://mynapoleon.napoleonproducts.com/download/index/44/1
Changes, other than editorial, are denoted by a vertical line in the margin
note:

Napoleon Allure Series Specifications

General

Installation Type	Wall Mounted
Flame Speed	Adjustable
Fuel Type	Electric
Heating Area	Up to 400 sq. ft.
Flame Adjustment	Yes
Heat Output	5000 BTU
Control	Remote Control
Timer	Yes
Dimensions	Varies by model
Vent Type	Vent-free
