Napoleon Allure Series User Manual

EN
W415-1699 / 02.08.17
5
model designation
1.0 general information
1.1 dimensions
1.2 product information
This appliance has been tested in accordance with the GS Standards for fi xed and location-dedicated electric
room appliances in Europe. If you need assistance during installation, please contact your local dealer.
Description
Electric Fireplace
Type
3 Way Mounting Unit
Wall-Mount, Recess into Wall and
Assemble with mantel
Voltage
220-240V AC
Watts
MAX 1750-2000W
Net Weight Gross Weight
NEFL32FH-EU
34.6 lbs (15.7kg) 50.3 lbs (22.8kg)
NEFL42FH-EU
44.3 lbs (20.1kg) 60.2 lbs (27.3kg)
NEFL50FH-EU
50.9 lbs (23.1kg) 77.4 lbs (35.1kg)
NEFL60FH-EU
61.3 lbs (27.8kg) 88.1 (40kg)
NEFL72FH-EU
81.8 lbs (37.1kg) 117.3 (53.2kg)
NEFL100FH-EU
111.3 lbs (50.5kg) 159.4 (72.3kg)
A
B
G
F
E
D
C
FRONT VIEW
SIDE VIEW
TOP VIEW
Dimensions
ABCDEFG
NEFL32FH-EU
32"
(813mm)
21 5/8"
(550mm)
5"
(127mm)
20 1/2"
(520mm)
27 5/16"
(694mm)
12"
(304mm)
22 5/16"
(567mm)
NEFL42FH-EU
42"
(1067mm)
21 5/8"
(550mm)
5"
(127mm)
20 1/2"
(520mm)
37 1/2"
(951mm)
12"
(304mm)
32 5/16"
(821mm)
NEFL50FH-EU
50"
(1270mm)
21 5/8"
(550mm)
5"
(127mm)
20 1/2"
(520mm)
45 7/16"
(1154mm)
12"
(304mm)
40 5/16"
(1024mm)
NEFL60FH-EU
60"
(1524mm)
21 5/8"
(550mm)
5"
(127mm)
20 1/2"
(520mm)
55 5/16"
(1405mm)
12"
(304mm)
50 5/16"
(1278mm)
NEFL72FH-EU
72"
(1830mm)
21 5/8"
(550mm)
5"
(127mm)
20 1/2"
(520mm)
67 3/8"
(1711mm)
12"
(304mm)
62 5/8"
(1583mm)
NEFL100FH-EU
100"
(2540mm)
21 5/8"
(550mm)
5"
(127mm)
20 1/2"
(520mm)
95 3/8"
(2422mm)
12"
(304mm)
90 9/16"
(2300mm)

Napoleon Allure Series Specifications

General

Installation Type	Wall Mounted
Flame Speed	Adjustable
Fuel Type	Electric
Heating Area	Up to 400 sq. ft.
Flame Adjustment	Yes
Heat Output	5000 BTU
Control	Remote Control
Timer	Yes
Dimensions	Varies by model
Vent Type	Vent-free
