ossature fi ni
10.3 dégagements minimaux de l’enceinte
* Voir la section « évacuation ».
Sections d’évents
Lors du passage à travers un mur, utiliser l’espaceur coupe-feu W010-3440 (fourni).
Lors du passage à travers un plafond, utiliser l’espaceur coupe-feu W500-0096 (non
fourni).
note:
Top of
appliance
opening
0” if non-combustible finishing
is used such as brick and stone.
Combustible
material
Non-combustible
material
Combustible
Non-combustible
56”
(142.2cm)
ceiling
(min.)
27 1/2”
(69.9cm)
1”
(25.4mm)
46”
(116.8cm)*
6 1/2”
(16.5cm)
3”
(76.2mm)
top
1”
(25.4mm)
bottom
14”
(35.6cm)
Vent shield
Top of
combustible
opening
Center of
vent pipe
3" [76.2mm] minimum all sides for vertical venting.
3”
(76.2mm)
L’écran protecteur est téléscopique
et doivent être ajusté à protection
toute la profondeur de la
pénétration de la paroi combustible.
note:
**
** Dégagements dedans l’enceinte peut être élevés, voir la
section « dimensions minimaux de l’encadrement ».
0” (0mm) si les
matériaux incombustibles sont
utiliser comme la brique ou la
pierre.
Incombustible
L’écran protecteur (Non
requis pour BL36-1)
Matériau
combustible
Matériau
incombustible
Plafond
Dessus de
l’ouverture
de l’appareil
Dessus de
l’ouverture
combustible
0” vers le bas de
l’appareil
0” aux contraintes
latérales
0” pour retourner les impasses
1” (25,4mm) des côtés d’évent
toute côtés d’évacation verticale.
