4.9 CONDENSATE DRAIN CONNECTION
H68.4
C - Hose Clamp 1X
B - AC Hose = 5/8” ID
B - AC Hose 5/8”
extra water.
1. Place clamp
over hose
opening.
2. Attach hose to
AC drain.
3. Tighten clamp
and secure.
Add water into
drain B opening.
B
B
B
Drain
B
Floor drain
GOOD PRACTICE
AC Hose
T-vent
fitting
Discharge condensate hose into an
OPEN TO ATMOSPHERE floor drain.
T- vent fitting would provide
RELIEF TO
A PRESSURE
of the downstream drain.
B
B
C
C
B
B
B
In order for air conditioner
to operate, this trap has to be
filled with water as shown.
2 3
5
DO NOT DRAIN THE CONDENSATE OUTDOORS.
DO NOT RUN THE CONDENSATE LINE THROUGH AREAS WHERE FREEZING MIGHT OCCUR.
DO NOT SUBMERGE THE DRAIN HOSE TERMINATION UNDER WATER BECAUSE
IT WILL CREATE AIR TRAP AND CAUSE FLOODING.
NOTE
CAUTION
! !
1
64
5/8” ID
THE CONDENSATE HOSE LEAVING THE SIDE OF THE APPLIANCE SHALL FOLLOW A DOWNWARD
SLOPE TO THE BUILDING DRAIN AT ALL TIMES. CONDENSATE FROM THE OUTLET OF THE DRAIN
TRAP ASSEMBLY MUST BE CONVEYED TO A FLOOR DRAIN, OR TO A CONDENSATE PUMP.
A properly functioning condensate trap provides discharge of water from the cooling coil drain pan, while
the water seal (the water level maintained in the trap) prevents the  ow of ambient air in or out of the unit.
The pre-fabricated condensate drain connection hose (with integral P trap) for air conditioning section
is included but not installed. Refer to steps 1-6 below to connect the drain hose to the existing drainage
system and to prepare a water seal into the trap:
