Napoleon Condo Pack - Page 30

30
IOM
IOM
W415-2288 / 08.29.2019
5.1.4 Electrical Panel
RED
RED
RED
BROWN
ORANGE
BROWN
WHITE
BLACK
BLACK
BLACK
BLACK
BLACK
RED
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
RED
RED
RED
RED
RED WHITE
BLUE
WHITE
BLUE
RED
RED
GREEN
WARNING
! !
YELLOW
G
W
C
Y/Y2
R
2
Terminal Block
G=Fan
W=Heat
C=Common
Y/Y2=Cool
R=Power
TERMINAL CONNECTIONS
DO NOT USE A COMMON MOTOR SPEED
FOR MULTIPLE OPERATIONS
(HEATING, COOLING AND CONTINUOUS
FAN) AS THIS WILL CAUSE THE UNIT
TO MALFUNCTION, LEADING TO
POSSIBLE PROPERTY DAMAGE OR INJURY.
EACH APPLIANCE FUNCTION MUST HAVE
ITS OWN DEDICATED FAN SPEED.
REFER TO SECTION 6.3.4.
Heater
Panel
1
2
3
Low Voltage
Fuse 2.5 A
A - POWER HARNESS
B - MOTOR HARNESS
X13
MOLEX
CB1
60A
30A
CB2
Breaker *
Breaker *
THERMOSTAT
1
Relay
Relay
2
3
Relay
POWER
DISTRIBUTION
BLOCKS
FUSE HOLDERS
SPEED 1
SPEED 2 SPEED 3 SPEED 4 SPEED 5
Transformer
Ground
Connection
Power Cable
* Control panel for 15 kW Heating Module shown. The number of breakers and relays on the control panel will vary depending
on the heating capacity of the unit. Refer to section
“5.2.4 Electrical and Physical Data”.
