55
IOM
W415-2288 / 08.29.2019
TABLE 11.
P-E CABINET, FAN AND BLOWER ASSEMBLY PARTS LIST:
REMARQUE : * PART NUMBERS MUST INCLUDE COLOR CODE TP1SP (EG.W475-0947-TP1SP)
TAUPE=TP1SP
REMARQUE : ^ ITEM NOT SHOWN
REMARQUE : ** THIS CONDENSER FAN MOTOR HAS TWO SPEEDS. FOR A24A CONNECT SPEED 2.
ITEM NO.
W010-4527
PART NUMBER DESCRIPTION
QTY
1 1 W062-0041 BLOWER, 10-6T HOUSING (GF)
2 1 W010-4537 ASSY, PROGRAMMED X13 1/3HP MOTOR (A24A)
3 1 W080-1925 BRACKET, BLOWER MOUNT LS (A24A)
4 1 W080-1926 BRACKET, BLOWER MOUNT RS (A24A)
5 1 W080-1924 BRACKET, BLOWER MOUNT BACK (A24A)
6 1 W361-0345 INSULATION,DUCTLINER 2.625"X21.25" (CP)
7 1 W361-0343 INSULATION, AC DIVISION (7"X1") (CP)
8 1 W361-0344 INSULATION,BLOWER DIVISION (20"X6.75") (CP)
9 1 W475-1655 PANEL, BLOWER DIVISION (A24A)
10 1 W080-1964 BRACKET, FRONT MOUNTING (CP)
11 1 W525-0054 GUIDE, LOWER (CONDO PACK)
12 1 W670-0531 TERM.,A/C CONTACT.2 POLE BOX LUG(ACHP)
13 1 W435-0083 CAPACITOR, 50+5MFD, 440V (CACM B)
14 1 W540-0020 RING,VENTURI 18.25"IDX1.00"H ABS UV(CP)
15** 1 W435-0091** MOTOR, CONDENSER ECM 1/3HP (A18A)
16 1 W290-0889 GASKET, INTAKE/EXHAUST (P-C)
17 1 W200-0793 FLASHING, INTAKE/EXHAUST P-E 2TON (CP)
18 1 W361-0347 INSULATION,DUCTLINER (21.25"X15.25)(CP)
19 1 W361-0346 INSULATION, AC DIVISON (7"X18.125") (CP)
20* 1 W080-1982* BRACKET, SOLID 11EER 2TON P-E (CP)
21* 1 W475-0947* PANEL, FURNACE SIDE ACCESS PWDR (CHAMUA)
22 1 W525-0043 GUIDE, FURNACE UPPER (CONDO PACK)
23 1 W018-0234 BAFFLE, FURNACE REAR (CP)
24 1 W018-0235 BAFFLE, FURNACE SIDE (CP)
25 1 W200-0537* COVER, RH SIDE
26 1 W200-0538* COVER, BACK
27
^
1 W750-0326
^
WIRE,HARNESS CONDO PACK X13 LOWER (ACHP)
28
^
1 W750-0474
^
WIRE, HARNESS COMPRESSOR 55" (A24) (CP)
29
^
1 W750-0348
^
WIRE, HARNESS POWER LOWER G/AC (CACM)
30* 1 W305-0019*
GRILLE, LOWER TAUPE POWDER (CP)
31* 1 W010-4529*
GRILLE, UPPER TAUPE POWDER P-S(CP)
32* 1 W500-0832* PLATE, 1” POWER SUPPLY FOR ELECTRIC
33* 1 W500-0831* PLATE, 1-1/8” POWER SUPPLY FOR ELECTRIC
34* 1 W500-0830* PLATE, 1-3/8” POWER SUPPLY FOR ELECTRIC
