TABLE 12.COOLING SECTION PARTS LIST:
ITEM NO.
A24A
PART NUMBER DESCRIPTION
QTY
1 1 W770-0015
HX MC, FLAT COND 940.2MM X 661MM (CP)
2 1 W290-0315
INSULATION,FRONT PANEL SEAL 1/8" FFM
3 1 W250-0012
FILTER, 16"X25"X1" HH (ACHP)
4 1 W770-0014
HX MC, EVAPORATOR 403.3MMX676.8MM (CP)
5 2 W450-0236
COREMAX CORE NUT (1/2-20 X 7/16--20)
6 2 W450-0237
1/2-20 HEX JAM NUT (BRASS)
7 2 W120-0090
CAP, 1/4 WITH O-RING
8 1 W290-0256-SER
GASKET, D-CHANNEL EPDM 3/4"X1/2" (ACHP) 37” LONG
9 1 W290-0910-SER
GASKET, 1/16" x 1/2" SG-411-A (CP) 27.5” LONG
10 1 W290-0910-SER
GASKET, 1/16” x 1/2” SG-411-A (CP) 41” LONG
11^ 1 W172-0026^
*COMPRESSOR, 2T (A24A) (CP)
11A^ 1
W200-0678^
COVER, COMPRESSOR WIRE TERM
11A^ 1
W450-0248^
NUT, COMPRESSOR WIRE TERM
11A^ 1
W290-0365^
GASKET, COMPRESSOR WIRE TERM
12 3 W315-0021
*GROMMET, 1.5/2T COMPRESSOR MOUNT (CP)
13 3 W315-0022
GROMMET SPACER,COMPRESSOR MOUNT(CACM B)
14 3 W735-0051
WASHER, 3/8" x 7/8" x .045" FLAT SS
15 3 W065-0046
BOLT, 5/16"X1-3/4" LONG TRIOBULAR (CACM)
16 1 W490-0869
PIPE, 5/8"OD SUCTION (A24A)
17 1 W010-4522
ASSY, SERV.TO SUCTION PIPE (A24A)
18 1 W010-4523
ASSY, SERV. TO LIQUID PIPE (A24A)
19 1 W010-4524
ASSY, LIQ.LINE FILTER DRIER (A24A)
20 1 W010-4525
ASSY, DISCHARGE LINE (A24A)
21 1 W010-4650
ASSY, LIQUID/EVAP BLEED TXV 2T (A24A)
22 1 W080-1956
BRACKET, SEAL 42" RH (CP)
23 1 W080-1957
BRACKET, COIL SEAL RH (CP)
24* 1 W475-1723*
PANEL, TOP PDWR COAT (CP)
25* 1 W475-1725*
PANEL, RIGHT SIDE 39" PWDR COAT (CP)
26 2 W290-0907 SER
GASKET, 1/8" X 2" SG-411-A (CP) 40” LONG
27** 1 W010-0001-SER**
TOP DOOR PARTS REPLACEMENT
28** 1 W010-0002-SER**
BTM DOOR PARTS REPLACEMENT
NOTE: * PART NUMBERS MUST INCLUDE COLOR CODE TP1SP (EG.W475-1723-TP1SP)
TAUPE=TP1SP
NOTE:** CONTACT HVAC ENG.
NOTE: ^ MUST BE ORDERED WITH 11A ACCESSORIES (NOT SHOWN)
