59
IOM
W415-2288 / 08.29.2019
ITEM NO.
E15A
E10A
E07A
E05A
PART NUMBER DESCRIPTION
QTY QTY QTY QTY
1 1 - - - W010-3584^ ASSY, ELECTRIC HEATER PANEL 15kW
1 - 1 - - W010-3538^ ASSY, ELECTRIC HEATER PANEL 10kW
1 - - 1 - W010-3583^ ASSY, ELECTRIC HEATER PANEL 7.5kW
1 - - - 1 W010-3582^ ASSY, ELECTRIC HEATER PANEL 5kW
2 3 2 2 1 W660-0184 TEMPERATURE CUT-OUT AUTO RESET
3 3 2 - 1 W660-0185
FUSIBLE LINK 170.6F (77
°C)
3 - - 2 - W660-0186
FUSIBLE LINK 161.6F (72
°C)
4 1 - - - W010-3695^^ ASSY, CONTROL PANEL 15 kW
4 - 1 - - W010-3694^^ ASSY, CONTROL PANEL 10 kW
4 - - 1 - W010-3693^^ ASSY, CONTROL PANEL 7.5 kW
4 - - 1 W010-3692^^ ASSY, CONTROL PANEL 5 kW
5 1 1 1 1 W670-0535 TERMINAL BLOCK
6 1 1 1 1 W670-0532 TERMINAL, THERMOSTAT FUSE BLOCK 1/4”
7 1 1 1 1 W285-0013 FUSE, GLASS 2.5A, 250V
8 1 - - 1 W660-0187 BREAKER 30A
8 - - 1 - W660-0188 BREAKER 45A
8 1 1 - - W660-0189 BREAKER 60A
9 3 2 2 1 W660-0190 RELAY T-92
10 2 2 2 1 W190-0106 TIME-DELAY RECTIFIERS CONTROL BOARD
11 1 1 1 1 W707-0018 TRANSFORMER, 240/24V 40VA
12 2 2 2 2 W735-0032 WASHER, 1/4” VULCANIZED FIBRE (GREY)
13 2 2 2 2 W670-0530 DISTRIBUTOR BLOCK, 175AMP
14 2 2 2 2 W285-0010 FUSE HOLDER, 2 POLE, 600V, 30A CLASS CC
15 2 2 2 2 W285-0008 FUSE, 5 AMP FOR ALL CEHM
16 2 2 2 2 W285-0017 FUSE, 25 AMP FOR A24A
17 2 2 2 2 W735-0028 WASHER, #12 FLAT BRASS
18 1 1 1 1 W715-0887 TRIM, 402 9/32” PRESS STYLE (2FT LG)
19 1 1 1 1 W670-0525 GROUND LUG
20 2 2 2 2 W290-0300 GASKET, CEHM MODULES
21 1 1 1 1 W750-0363 HARNESS, ELECTRIC FURNACE MODULE
22 1 1 1 1 W750-0364 WIRE HARNESS, AC/GAS/ELEC UPPPER
23 1 1 1 1 W750-0325 WIRE HARNESS, CONDO PACK X13 UPPER
NOTE: ^ ITEM# 1 INCLUDES ITEM#’S 2,3
NOTE: ^^ ITEM# 4 INCLUDES ITEM#’S 5,6,7,8,9,10
TABLE 13.
P-E HEATING MODULE PARTS LIST:
