Napoleon TQ285X Instructions

www.napoleongrills.com
145
Item Part # Descripon
1 N325-0085-SS1SG handle cart x
2 N120-0023 cap nylon x
3 Z570-0036 screw 1/4-20 x 7/8" x
4 N325-0086-SS1SG handle cart shelf x
5 N120-0022 cap shelf x
6 N120-0021 cap shelf x
7 N570-0013 screw #8 x 5/8" x
8 N590-0237 shelf le / right x
9 N570-0076 screw #8 x 1/2" x
10 N570-0111 screw #14 x 1 1/4" x
11 N010-0804-SS1SG cart front beam x
12 N010-0805-SS1SG cart rear beam x
13 N525-0047-BK1SG rail sliding track x
14 N530-0051 regulator 30 mbar x
N530-0052 regulator 50 mbar x
15 N080-0326-BK1SG bracket regulator mount x
16 N570-0026 screw #14 x 1/2" x
17 N450-0039 post nut / shelf pivot x
18 Z735-0009 washer M5 x
19 N570-0107 screw 10-24 30mm x
20 N135-0045-BK1HT base x
21 N570-0104 screw 10-24 x 3/8" x
22 N475-0319 control panel x
23 N010-0773 manifold 30 mbar x
N010-0825 manifold 50 mbar x
24 N570-0078 screw M4 x 8mm x
25 N585-0089-BK1HT heat shield control panel x
26 N380-0020-RD control knob x
27 N200-0109-BK1HT cover right leg x
28 N200-0108-BK1HT cover le leg x
29 N710-0079 drip pan x
30 N010-0821 bracket drip pan le x
31 N010-0822 bracket drip pan right x
32 N570-0073 screw 1/4-20 x 3/8" x
33 Z570-0033 screw 10-24 x 12mm x
34 N100-0047 burner right x
35 N100-0046 burner le x
36 N655-0158 support handle le x
37 N655-0159 support handle right x
38 N570-0107 screw 10-24 x 30mm x
39 N325-0082 handle top/boom x
40 N485-0020 clevis pin x
41 N485-0021 coer pin x
42 N080-0302 cross light bracket x
43 N305-0087-BK2FL cooking grid le x
44 N305-0088-BK2FL cooking grid right x
Parts List

Napoleon TQ285X Specifications

General

Brand	Napoleon
Model	TQ285X
Category	Grill
Language	English
