Mounting on a Rack
You can use the following rack mount kits to mount the controller and other DIN rail-
mountable equipment on a standard 482.6 mm (19 in.) rack.
• Industrial Rack Mount Kit, 786411-01
• NI Rack-Mounting Kit, 781989-01
Note You must use the appropriate NI DIN rail mounting kit for your model in
addition to a rack-mounting kit.
Mounting on a Desktop
You can use the NI desktop mounting kit to mount the cRIO-904x on a desktop.
What to use
• cRIO-904x
• Screwdriver, Phillips #2
• NI desktop mounting kit, 779473-01
– Desktop mounting brackets (x2)
Figure 29. Mounting the 4-slot cRIO-904x on a Desktop
cRIO-904x User Manual | © National Instruments | 37
