implementing a type-A male connector. Use a USB Type-C multiport adapter to
simultaneously use this port as a display output and a USB host port.
The following NI USB Type-C adapters are available for the cRIO-904x.
Table 2. NI USB Type-C Adapters for cRIO-904x
Adapter Length Part Number
USB to DVI Adapter with Retention, USB Type-C Male to DVI-D
Female
0.5 m 143558-0R5
USB to VGA Adapter with Retention, USB Type-C Male to VGA
Female
0.5 m 143557-0R5
USB Cable with Retention, Type-C Male to Type-A Female, USB
3.1, 3A
0.5 m 143555-0R5
The following NI USB Type-C cables with retention are available for the cRIO-904x.
Table 3. NI USB Type-C Cables for cRIO-904x
Cable Length Part Number
USB Cable with Retention, Type-C Male to Type-C Male, USB 3.1,
3A
0.3 m 143556-0R3
1 m 143556-01
1 m 143556-02
PFI 0
The Programmable Function Interface (PFI) terminal is a SMB connector.
Table 4. Signal Descriptions
Signal Reference Description
PFI 0 — Programmable Function Interface—You can configure the PFI terminal
as a timing input or timing output signal for AI, AO, DI, DO, or
counter/timer functions.
Note The PFI 0 terminal can only be programmed with NI-DAQmx.
Power Connector
The cRIO-904x has a power connector to which you can connect a primary and secondary
power supply. The following table shows the pinout for the power connector.
8 | ni.com | cRIO-904x User Manual
