PXIe-4466/4467 Calibration Procedure
16 ni.com/services
Initial Test Connection
Note
Initial test connection is same as AI Offset, as shown in Figure 1.
Verification Procedure
Complete the following procedure to verify the AI flatness accuracy.
Repeat 2 times, once for each channel.
1. Connect the AI channel under test to the Calibrator as shown in Figure
1.
Repeat 6 times, once for each gain setting.
Repeat 4 times, once for each frequency in
T
6
.
2. Configure the calibrator to generate an output with the frequency
listed in Table 6 and amplitude listed in Table 7.
Table 7: AI Flatness Inputs
Device Gain (dB)
Configuration Value
Amplitude (Vrms) Frequency (Hz)
-20 6.3 1000
-10 6.3 1000
0 6.3 1000
10 2.0 1000
20 0.63 1000
30 0.2 1000
