PXIe-4466/4467 Calibration Procedure
© National Instruments Corporation 15
The calculated amplitude is used to verify the gain accuracy of the
channel under test at the tested gain setting.
As an example, use the Extract Single Tone Information VI to help
calculate RMS. Note that the output of this VI is peak amplitude, and
must be divided by √2 to convert to RMS.
7. Stop and clear the task.
AI Gain Flatness Verification
Test Limits
Table 6: AI Flatness Verification Limits
Device Gain (dB)
Calibrator
Output
Frequency (kHz)
As-Found Test Limit
Lower Limit Upper Limit
-10 and -20
1 V
1kHz
20 0.97724 * V
1kHz
1.02329 * V
1kHz
45 0.93325 * V
1kHz
1.07152 * V
1kHz
100 0.89125 * V
1kHz
1.12202 * V
1kHz
0, 10, 20 and 30
1 V
1kHz
20 0.99931 * V
1kHz
1.00069 * V
1kHz
45 0.99713 * V
1kHz
1.00288 * V
1kHz
100 0.99083 * V
1kHz
1.00925 * V
1kHz
