PXIe-4466/4467 Calibration Procedure
© National Instruments Corporation 31
AO Common-Mode Gain and Offset Verification
Test Limits
Table 23: AO Common-Mode Gain and Offset Limits
Test Point (V)
As-Found Test Limit
As-Left Test Limit
Lower Limit
(V)
Upper Limit
(V)
Lower Limit
(V)
Upper Limit
(V)
0 -0.00600 0.00600 -0.00152 0.00152
1 0.99325 1.00675 0.99790 1.00210
2 1.99250 2.00750 1.99732 2.00268
3 2.99175 3.00825 2.99674 3.00326
4 3.99100 4.00900 3.99616 4.00384
5 4.99025 5.00975 4.99558 5.00442
