PXIe-4466/4467 Calibration Procedure
30 ni.com/services
Table 22: Basic Function Generator Parameters
Parameter Value
Signal Type Sine Wave
Frequency 1000 Hz
Amplitude* Amplitude from Table 17
Sampling Info>>Sampling Rate 250000 S/s
Sampling Info>>Number of Samples 12500
*Refer to Table 17 for details about the correlation between AO Gain, DMM Range, and
Signal Amplitude.
6. Write the resulting waveform to AO and start the task.
7. Measure the output voltage with the DMM, and record as V
1kHz
for
future calculations. The first measured amplitude represents V
1kHz
referenced in Table 20. Subsequent test points will be calculated
based on V
1kHz,
as shown in Table 20.
8. Stop the task.
9. Compare the result with the limits in Table 20.
