PXIe-4466/4467 Calibration Procedure
© National Instruments Corporation 25
20 -20 1
0.63 *
ξ
2
30 -30 1
0.2 *
ξ
2
3. Configure an AO Voltage channel task using the values in Table 18.
Table 18: AO Setup
Configuration Value
Physical Channels Dev_name/aox
AO Gain* Gain from Table 17
Output Terminal Configuration Configuration from Table 15
Rate 250000 S/s
Sample Mode Continuous Sample
Samples Per Channel 25000
*Refer to Table 17 for details about the correlation between AO Gain, DMM Range, and Signal
Amplitude.
4. Call Basic Function Generator using the parameters in Table 19.
Table 19: Basic Function Generator Parameters
Parameter Value
Signal Type Sine Wave
Frequency 1000 Hz
Amplitude* Amplitude from Table 17
Sampling Info>>Sampling Rate 250000 S/s
Sampling Info>>Number of Samples 25000
*Refer to Table 17 for details about the correlation between AO Gain, DMM Range, and
Signal Amplitude.
