GUITAR RIG KONTROL Hardware Reference – 45
8.2 Audio Specications
Audio Inputs (A/D)
Channels 2
Sample Rate 44.1, 48, 88.2, 96, 192kHz
Bit Resolution 16, 24 Bit
Converter Cirrus Logic
Instrument Inputs
Input Impedance 1M Ohm
Full Scale Level at Maximum Gain -11,5 dBu
Maximum Input Level +16dBu
SNR (weighted) >100dB
THD+N 0,009%
Frequency Response +/- 0,5dB 20Hz – 24KHz
Dynamic Range 105dB (ADC)
