GUITAR RIG KONTROL Hardware Reference – 46
Line Inputs
Input Impedance 44 KOhm
Full Scale Level at Maximum Gain -5,5dBu
Maximum Input Level +16dBu
SNR (weighted) >100dB
THD+N 0,009%
Frequency Response +/- 0,5dB 20Hz – 36KHz
Dynamic Range 105 dB (ADC)
Audio Outputs (D/A)
Channels 2
Sample Rate 44.1, 48, 88.2, 96, 192 kHz
Bit Resolution 16, 24 Bit
Converter Cirrus Logic
