GUITAR RIG KONTROL Hardware Reference – 47
Line Outputs
Output Impedance 100 Ohm
Maximum Output Level +6,3dBu
SNR (weighted) >100dB
THD+N 0,010%
Frequency Response +/- 0,5dB 22Hz – 44KHz
High/low level switch Full scale 5Vpp / -14dB
Headphone Output
Load Impedance 8-600 Ohm
Maximum Output Level 1,61V rms @ 100 Ohm
SNR (weighted) >91dB
THD+N (60 Ohms) 0,013%
Frequency Response +/- 0m5dB 22Hz – 44KHz
