User and Service Manual Xltek
®
EMU40EX™
55
Discrete Saturation Transform (DST™) plot
The DST plot has two peaks: the peak corresponding to the higher saturation is selected as the SpO
2
value. This entire sequence is repeated once every two seconds on the most recent four seconds of raw
data. The Masimo SET
®
pulse oximeter SpO
2
therefore corresponds to a running average of arterial
hemoglobin saturation that is updated every two seconds.
Pulse Oximeter Accessories
PC Series Cable: Connects the pulse oximeter module to the oximetry sensors. Transfers LED drive
power to the oximetry sensors from the pulse oximeter. The pulse oximeter receives the detector signal
from the oximetry sensor through the PC series cable.
LNCS
®
Series Oximetry Sensors: Low Noise Cabled Sensors (LNCS) and integrated cables are
designed to provide optimal pulse oximetry performance. Offering additional protection from liquids and
improved moisture resistance, these sensors perform accurately with motion, low perfusion, and intense
ambient light. LNCS
®
sensors can be used with all Masimo SET
®
pulse oximeters.
Available Oximeter Sensors
EMU40EX Masimo LNCS Oximetry Kit
MASIMO PATIENT CABLE 12' - CONNECTS TO ALL MASIMO PULSE
OXIMETER SENSORS
Masimo LNCS Reusable 14ft Patient Cable
Masimo LNCS DBI Reusable Adult Soft with 3ft Cable
Masimo LNCS Disposable Adult Sensor with 18" Cable
Masimo LNCS DCI Reusable Adult Finger Clip Sensor with 3ft Cable
Masimo LNCS DCIP Reusable Pediatric Finger Clip Sensor with 3ft Cable
Masimo LNCS Y1 Reusable Multisite Sensor
Requires disposable wraps, standard and petite sizes available
