NV10LT/NV7.5LT INSTALLATION MANUAL UNPACKING AND POSITIONING
VERSION 5.0 2021-03-01 PAGE 2.2.7
Figure 2.2.5: RF Output Connector Assembly Detail - 7/8 inch EIA (optional)
OUTPUT
CONNECTOR
CUP
OUTPUT PLATE
SPACER PLATES
ADAPTER
TORQUE OUTPUT CONNECTION TO 60 IN-LBS
