NV10LT/NV7.5LT INSTALLATION MANUAL INSTALLING OPTIONS
VERSION 5.0 2021-03-01 PAGE 2.3.1
SECTION 2.3: INSTALLING OPTIONS
The NV10LT/NV7.5LT transmitter is factory configured and shipped to operate with the customer’s
desired ac power source voltage and RF output connector size. There are options available for various
other features, including dual exciter, UPS interface, redundant LVPS, and remote interfacing. These
options may be installed in one of two ways:
 You install and configure options at your site, using kits and instructions provided by Nautel.
Each option has a separate kit.
 Pre-arrange for Nautel to install and configure options at the factory prior to shipping.
Table 2.3.1 shows the standard (default) configuration of the NV10LT/NV7.5LT, as well as available
options. Each option references a schedule of installation and how to install the option. Review the
options to determine which, if any, apply to your installation.
If you did not purchase any options for your NV10LT/NV7.5LT and intend to operate with the standard
(default) configuration, proceed to Section 2.4, “Connecting to Station Reference Ground”.
NOTE: When an option is installed (UPS interface, dual exciter, etc.), the extra parts removed (e.g.,
blank exciter panel, AC LED cover) from the original configuration are placed in the Ancillary kit.
Table 2.3.1: NV10LT/NV7.5LT Available Options
ITEM/
FEATURE
STANDARD
CONFIGURATION
AVAILABLE
OPTIONS
WHEN TO
INSTALL?
HOW TO INSTALL?
Exciter Single Exciter,
integrated into
controller (NAE106*)
Exciter B (NAE107*) Station
convenience
See
“Upgrading to Dual
Exciter” on page 2.3.2
UPS Interface No UPS interface UPS Interface Assembly and
ac input connectors
(219-5140-02); user
provides UPS and wiring
Station
convenience
See
“Installing the UPS
Interface” on page 2.3.3
LVPS Single LVPS A (UG132) LVPS B (UG132) Station
convenience
See
“Redundant LVPS
Upgrade” on page 2.3.4
Remote
Control/Monitor
Connectors on
controller (NAE106*)
rear panel
Remote Interface PWB Kit
(NAPI143/01)
Station
convenience
See
“Installing the Remote
Interface PWB” on
page 2.3.5
Internal Audio
Processor
No internal audio
processor
Orban Inside Kit(s) (for one
or both exciters, as desired)
Station
convenience
See
“Installing the Orban
Inside Card” on
page 2.3.6
