NV10LT/NV7.5LT INSTALLATION MANUAL CONNECTING TO STATION REFERENCE GROUND
PAGE 2.4.2 VERSION 5.0 2021-03-01
Figure 2.4.1: Station Reference Ground Strap Connection
E1
3/8-inch
stud
IMPORTANT !
Do not allow conductor to contact the
transmitter chassis at any other point.
To Station
Reference Ground
Conductor
(copper strap shown)
