Nautilus Bowflex VeloCore - Specifications; Basic Assembly Tips

Assembly / Owner’s Manual
6
SPECIFICATIONS
Maximum User Weight: 147 kg (325 lbs.)
16” monitor 22” monitor
Machine Weight without Dumbbells: 67.6 kg (149 lb.) 69.1 kg (152.3 lb.)
Approx. Screen Size (measured diagonally): 39.6 cm (15.6”) 54.6 cm (21.5”)
Weight of Dumbbells (supplied in U.S./Canada): 2.7 kg (6 lbs.)
Total Surface Area (footprint) of equipment: 9290.2 cm
2
(1440 in
2
)
Power Requirements
(Power Adapter):
Input Voltage: 100-240V AC, 50-60Hz, 0.5A
Output Voltage: 12V DC, 5A
(Arm Band - supplied in U.S./Canada): Rechargeable lithium battery
DO NOT dispose of this product as refuse. This product is to be recycled. For proper
disposal of this product, please follow the prescribed methods at an approved waste
center.
Before Assembly
Select the area where you are going to set up and operate your machine. For safe operation, the location must be on a hard, level surface. Allow a
workout area of a minimum 2.7 m x 1.8 m (108” x 72”).
Basic Assembly Tips
Follow these basic points when you assemble your
machine:
• Read and understand the “Important Safety
Instructions” before assembly.
• Collect all the pieces necessary for each assembly
step.
• Using the recommended wrenches, turn the bolts
and nuts to the right (clockwise) to tighten, and the
left (counterclockwise) to loosen, unless instructed
otherwise.
• When attaching 2 pieces, carefully lift and look
through the bolt holes to help insert the bolt through
the holes.
• The assembly requires 2 people.
Specifications
0.6m
24”
2.7m 108”
1.8m
72”
0.6m
24”
0.6m
24”
0.6m
24”
61.2 cm
(24.1”)
151.8 cm
(59.8”)
133.6 cm
(52.6”)
16” monitor
61.2 cm
(24.1”)
151.8 cm
(59.8”)
140.3 cm
(55.3”)
22” monitor
