Nautilus Bowflex VeloCore - Assembly Instructions; Hardware and Tools

Assembly / Owner’s Manual
8
Tools
Included
13 mm/14 mm
15 mm/17 mm
1. Attach Stabilizers to Frame
Note: The hardware (*) is pre-installed. Remove the nut from the end of the long screws and discard the nut. If a tube is pre-installed in the stabilizer
bracket, remove and discard safely.
4 mm
Hardware
Assembly
*
*
*
*
*
*
X4
X4
6mm
6mm
3
2
1
*
X4
13mm
Hardware is pre-installed on the machine.
Note: Selected pieces of the pre-installed hardware have been provided as spares in the bag.
#2
6 mm
