Nautilus Bowflex VeloCore - Parts Identification

Assembly / Owner’s Manual
7
Item Qty Description Item Qty Description
1 1 Frame 12 1 Console (22” console option shown)
2 1 Stabilizer, Front 13 1 End Cap, Console Mast *
3 1 Stabilizer, Rear 14 1 Pedal, Left (L)
4 1 Handlebar 15 1 Pedal, Right (R)
5 1 Handlebar Post 16 2 Dumbbell Holder
6 1 Seat Stem 17 2 Water Bottle Holder
7 1 Seat Assembly 18 1 AC Adapter w/Cord
8 1 End Cap, Seat Stem * 19 2 Dumbbell
9 3 Adjustment Handle, Handlebar / Seat * 20 2 Shoe Clips (Cleats) *
10 1 Console Mast 21 1 Bluetooth
®
Heart Rate (HR) Armband
11 1 Adjustable Console Mast
* These items are in bag with Tools.
PARTS
20
4
5
1
6
7
8
9
9
9
3
2
14 (L)
17
16
(X2)
15 (R)
10
19
11
18
12
21
13
Parts
