18
10. Remove Hardware from Console
Note: Hardware (*) is pre-installed and not on the Hardware Card. If desired, apply
the French Canadian overlay to the Console face.
11. Route Cables through the Console Junction Cover and Static Handlebars and Place onto the Console Mast
NOTICE: Do not crimp the Console Cables. Be aware that the Static Handlebar is not securely attached.
*
X4
#2
3
2
4
To Next Page
