Nautilus E616 User Manual

6
SPECIFICATIONS
Before Assembly
Select the area where you are going to set up and operate your machine. For safe operation, the location must be on a
hard,levelsurface.Allowaworkoutareaofaminimum76”x120”(193cmx305cm).Besurethattheworkoutspace
you are utilizing has adequate height clearance, taking into consideration the height of the user and the maximum incline
of the elliptical machine.
Basic Assembly Tips
Followthesebasicpointswhenyouassembleyourmachine:
• Read and understand the “Important Safety Instructions” before assembly.
• Collect all the pieces necessary for each assembly step.
• Using the recommended wrenches, turn the bolts and nuts to the right (clockwise) to tighten, and the left (counterclock-
wise) to loosen, unless instructed otherwise.
• When attaching 2 pieces, lightly lift and look through the bolt holes to help insert the bolt through the holes.
• The assembly can require 2 people.
Maximum User Weight: 300lbs.(136kg)
Machine Weight: 173.3lbs.(78.6kg)
Power Requirements:
 OperationalVoltage:120VAC
 OperatingCurrent: 2A
Regulatory Approvals:
 ULlisted,Rated120VAC,60HzInput,2A.
This product, its packaging, and components contain chemicals known to the State of California to cause cancer,
birthdefects,orreproductiveharm.ThisNoticeisprovidedinaccordancewithCalifornia’sProposition65.Ifyou
wouldlikeadditionalinformation,pleaserefertoourwebsiteatwww.nautilus.com/prop65.
63.2”
(160.5 cm)
71.5”
(181.7 cm)
26.7”
(67.7 cm)

Nautilus E616 Specifications

General

Type	Upright
Programs	29
Bluetooth Connectivity	Yes
User Profiles	4
Drive System	Belt
Display	LCD
Heart Rate Monitoring	Contact and Telemetry Enabled
Max User Weight	300 lbs
Warranty	10 years frame, 1 year labor
Flywheel	Perimeter Weighted
Product Weight	78.5 lbs (35.6 kg)
