Nautilus E616 - Hardware; Tools

8
Item Qty Description Item Qty Description
A 6 ButtonHeadHexScrew,M8x16(with
Loctite
®
adhesive)
G 8 Lock Washer, M8
B 4 Serrated Washer, M8 H 2 Pivot Sleeve
C 8 Wide Washer, M8 I 5 PhillipsHeadSelftapScrew,M4.2x16
D 4 ButtonHeadHexScrew,M8x16 J
2
Cap
E 2 Hex Head Screw, M8x20 K 5 Phillips Head Self tap Screw, M5x12
F 6 Wave Washer
HARDWARE / TOOLS
Tools
Included Not Included
6mm
(recommended)
A B C D E F
G H
I
J
K
#2
13 mm
15 mm
19 mm
