20
13. Connect Console Mast Cables to Cables from Handlebar Arms and Attach Rear Handlebar Shrouds
NOTICE: Connect the cables. Route the wire through the 3 guides inside the rear Handlebar Shroud and fit the
connectors inside the cavity as shown. Do not crimp cables. Make sure the inner edge of the Handlebar
Shroud is seated in the Water Bottle Holder Shroud.
1a
9
10
1a
2X
1a
2X
