5
Nautilus NS300X
PARTS LIST / BOX CONTENTS
# DESCRIPTION QTY # DESCRIPTION QTY
Main Base Frame ....................................
Rear Frame ..............................................
Front Upright Frame ...............................
Top Frame ...............................................
Calf Raise / Low Pulley Frame ...............
Top Stack Support Frame ......................
Cable Housing .........................................
2 inch Backing Plate ................................
3 inch Backing Plate ................................
Leg Extension Assembly ........................
Floating Pulley Bracket ...........................
Pop Pin - Seat Adjustment .....................
Pec Fly Mount .........................................
Pec Fly Cam .............................................
Right Pec Fly Arm ...................................
Left Pec Fly Arm ......................................
Pec Fly Handle.........................................
Press Arm ................................................
Press Arm Support Assembly ...............
Press Arm Handle - Right .......................
Press Arm Handle - Left .........................
Press Arm Pivot Shaft ............................
Press Arm Support Shaft .......................
Snap Cap - Small ....................................
Snap Cap - Large ....................................
Roller Bar .................................................
Foam Roller 8” L .....................................
Roller End Cap ........................................
Plastic Cap ...............................................
Plastic Washer.........................................
Seat Pad...................................................
Back Pad ..................................................
Seat Adjuster...........................................
Seat Cross Tube ......................................
Back Pad Tube .........................................
Back Pad Adjuster ...................................
Back Pad Adjustment .............................
Guide Rod ................................................
Weight Stack Bottom Plate ....................
Selector Stem..........................................
Top Weight ..............................................
Weight Plate ............................................
Guide Rod Holder ...................................
Weight Stack Cushion ............................
Double Floating Pulley Bracket ..............
4 1/2” Pulley ............................................
3 1/2” Pulley ............................................
3” Pulley ...............................................
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
35a
36
37
38
39
40
41
42
43
44
45
46
47
1
1
1
1
1
1
1
2
1
1
1
1
1
2
1
1
2
1
1
1
1
1
1
2
2
1
2
2
4
2
1
1
1
1
1
1
1
2
1
1
1
19
1
2
3
23
2
1
CABLES
Cable #1 - Low Row (136.5”).................
Cable #2 - Pull Down (228.75”) .............
Cable #3 - Leg Extension (164.25”) ......
Cable #4 - Pec Fly (104.25”) ..................
HARDWARE
Flat Head Screw - M8 ............................
Flat Head Screw - M4 ............................
Hex Bolt 1/2” x 4 1/2”L ..........................
Hex Bolt 3/8” x 4 1/4”L ..........................
Hex Bolt 3/8” x 4”L ................................
Hex Bolt 3/8” x 3 1/4”L ..........................
Hex Bolt 3/8” x 3”L ................................
Hex Bolt 3/8” x 2 3/4”L ..........................
Hex Bolt 3/8” x 2 1/2”L ..........................
Hex Bolt 3/8” x 2 1/4”L ..........................
Hex Bolt 3/8” x 2”L ................................
Hex Bolt 3/8” x 1 3/4”L ..........................
Cap Head Allen Screw 1”L ....................
Cap Head Allen Screw 1/2”L .................
Cap Head Allen Screw 3”L ....................
Button Head Allen Screw 1 3/4”L ........
Button Head Allen Screw 3/4”L ...........
1 3/8” x 1/2” Flat Washer .....................
1” x 1/2” Flat Washer ...........................
3/8” Flat Washer ....................................
1/2” Lock Nut..........................................
3/8” Lock Nut..........................................
Shim Washer ..........................................
Set Screw 5/16” x 1/4”L ........................
Pulley Spacer 1/2”L ...............................
Pulley Spacer 1”L ..................................
Step Spacer - 5/8”H ...............................
Step Spacer - 7/8”H ...............................
3/8” Curved Washer ..............................
ACCESSORIES and TOOLS
Lat Bar ....................................................
Rower Bar ...............................................
AB Strap .................................................
Felt Back Ankle Strap.............................
Dual Ring Handle ...................................
Chain .......................................................
Cable Clip ...............................................
Weight Selector Pin ...............................
Weight Stack Decals ..............................
M4 Allen Wrench ...................................
M5 Allen Wrench ...................................
M6 Allen Wrench ...................................
M8 Allen Wrench ...................................
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
93
80
81
82
83
84
85
86
87
88
89
90
91
92
1
1
1
1
1
1
1
2
1
7
13
5
1
4
14
3
2
2
2
2
4
4
4
87
7
47
4
6
2
1
10
2
4
1
1
1
1
1
1
4
1
19
1
1
1
1
