Nautilus R614 Service Manual

49
9. Using a #2 Phillips screwdriver, remove the screws that
secure the Right Rear Shroud. Slowly remove the Right
Shroud. Set the hardware and Right Shroud safely aside for
reassembly.
10. 8VLQJDPPKH[NH\DQGPPRSHQHQGZUHQFK
loosen and remove the hardware that attaches the back end
of the Seat Rail.
11. Using a 13mm open end wrench, loosen and remove
the hardware at the front of the Seat Rail. Set the hardware
safely aside.
X2
X2
