32
6. Bend the edges of the Top Shroud to disengage the
inside tabs from the Main Assembly, and slide the Top
Shroud up the Mast.
 8VLQJWKHPPKH[NH\UHPRYHWKHKDUGZDUHLQGLFDW-
ed) from the Mast. Gently pull the Mast out and disconnect
the cables. Set the hardware, Mast and Console, and Top
Shroud safely aside for reassembly.
NOTICE: Do not crimp the cables. This step may require
two people.
Note: Do not let the cables fall down inside the Frame.
X2
