Nautilus T618 User Manual

6
SAFETY WARNING LABELS AND
SERIAL NUMBER
Serial Number
Product Specication
CAUTION!
Risk of Injury to Persons - To Avoid injury, use
extremecautionwhensteppingontooro󰀨ofamoving
belt. Read instruction manual before using.
WARNING!
• Injury or death is possible if caution is not used
while using this machine.
• Keep children and pets away.
• Read and follow all warnings on this machine.
• Refer to the Owner’s Manual for additional
warnings and safety information.
•Theheartratedisplayedisanapproximation
and should be used for reference only.
• Not intended for use by anyone under 14 years
of age.
•Themaximumuserweightforthismachineis
350lbs(158kg).
• This machine is for home use only.
(The label on the machine is available in English and
French Canadian only.)
WARNING!
- Moving parts can crush and cut.
- Keep guards in place.
- Lock out power before servicing.
WARNING!
HAZARDOUS VOLTAGE.
- Contact may cause electrical shock or burn.
-Turno󰀨andlockoutpowerbefore
servicing.
