HARDWARE / TOOLS / BEFORE ASSEMBLY
Tools
Included
#2
6 mm
Item Qty Description Item Qty Description
A 4 ButtonHeadHexScrew,M8x50 F 18 FlatWasher,M8
B 4 ButtonHeadHexScrew,M8x25 G 13 SelfTappingScrew,M4.2x16
C 6 ButtonHeadHexScrew,M8x20 H 6 SelfTappingScrew,M3.9x9.5
D 4 SocketHeadCapScrew,M8x16 I 2 Flat Washer, M4
E 18 LockWasher,M8 J 4 PhillipsHeadScrew,M4x16
Note: Select pieces of Hardware have been provided as spares on the Hardware Card. Be aware that there may be
remaining Hardware after the proper assembly of your machine.
A B D
C E F
G
H
I J
