Nautilus T626 - Console Features

27
mph
3
km/h
2
ENTER
4
5
6
8
10
12
6
8
10
13
16
20
15
13
10
8
5
2
0
ENTER
Console Features
The Console provides important information about your workout and lets you control the resistance levels while you
exercise.TheConsolefeaturestouchcontrolbuttonstonavigateyouthroughtheexerciseprograms.
Console Display
Pacer Icon- represents the location of the Pacer during the Workout.
User Indicator Lights- The User indicator lights show where the User is in relation to the Pacer during the Workout.
FitnessScoreDisplay-TheFitnessScoreDisplayshowsthecurrentFitnessScoreoftheselectedUserProle.
Goal Display-The Goal Display shows the selected type of goal (Distance, Time or Calories) and the value for it.
User Placement Display- The User Placement Display shows the difference between the User and the Pacer. The arrows
tell if the User is in front (UP arrow) or behind (DOWN arrow) the Pacer.
COMPARE button- Push to select the desired Workout Pacer: Average, Best, or off.
USERbutton-PushtoselectthedesiredUserProle.TheActiveUserDisplaywilladjust
Increase () button- Increases the current value or moves through the options available
Left () button- Shifts the currently active segment, and moves through options
OKbutton-Conrmsinformationoraselection
Fan Button
Fitness Score Display Goal Display
User Indicator
Lights
Pre-Set
Incline
Buttons
User Placement
Display
Incline Enter
Button
Pre-Set
Speed
Buttons
Speed Enter
Button
Pacer Icon
