Nautilus U616 - Assembly Instructions Part 3; Install Console on Console Mast

11
4. Install Console on Console Mast
Note: Remove the preinstalled screws() from the back of the Console before you connect the cables. If desired, apply
the French Canadian overlay to the Console face.
NOTICE: Do not crimp the cables.
8
X4
#2
*
*
X4
#2
8
