27
(L)
(R)
6. Installation is the reverse procedure. Installation does
not require the use of the crank puller. Be sure the Crank
Armsareconnectedat180°fromeachother.
To reinstall the Pedals, carefully align the threads and hand
tightentopreventcross-threading.Thentightenfullywith
pedal wrench.
Note: The Left Pedal is reverse-threaded. Be sure
to attach Pedals on the correct side of the Bike.
Orientation is based from a seated position on the
bike. The Left Pedal has an “L”, the Right Pedal an
“R”.
7. Final Inspection
Inspect your machine to ensure that all hardware is tight and
components are properly assembled.
!
Do not use until the machine has been fully
assembled and inspected for correct performance
in accordance with the Owner’s Manual.
