Nautilus U618 - Crank Arms

26
4. ThreadtheCrankPullerintotheCrankArm(B).When
theCrankPullerisinthecorrectposition,only1-2threads
on the outer portion (CP2) of the Crank Puller should show.
Note: Be sure the end of the Bolt (CP1) of the Crank
PullerisushwiththeNut(CP2)asshown,before
use.
5. Using a wrench, turn the inner portion (CP3) of the
CrankPullerclockwise.TheCrankArm(B)willslideoffasit
is tightened.
CP1 CP2 CP3
B
CP2
CP3
Crank arm shown is on a 170 bike.
