Nautilus U618 - Page 59

59
NOTICE: It is necessary to remove the Shrouds for this procedure. Refer to the “Replace the Shrouds” procedure.
Note: Your machine may not match the image. For reference only.
1. Carefully remove the Left Shroud. Refer to the “Replace
the Shrouds” procedure in this manual.
2. CarefullydisconnectthePowerInletcable(A)inthe
Shroud from the wiring harness (B) on the motor.
Disconnect all power to the machine before you service it.
A
B
B
A
Recumbent bike
Upright bike
