SECTION5–MAINTENANCESCHEDULEANDSERVICEPROCEDURES

Figure30DrainintervalsforMaxxForce

DT,9,and10

applications.

1.Parkvehicleonlevelground.Setparkingbrakeandshift

transmissiontoparkorneutral.

2.Runengineuntiloperatingtemperatureisreached,thenshut

downengine.

GOVERNMENTREGULATION:Engineuids

(oil,fuel,andcoolant)maybeahazardtohuman

healthandtheenvironment.Handlealluids

andothercontaminatedmaterials(suchaslters,

rags)inaccordancewithapplicableregulations.

Recycleordisposeofengineuids,lters,and

othercontaminatedmaterialsaccordingtoapplicable

regulations.

WARNING

Topreventpersonalinjuryordeath,wear

protectiveclothingwhendraininghotoil.

WARNING

Topreventpersonalinjuryordeath,donotlet

engineuidsstayonyourskin.Cleanskinand

nailsusinghandcleanerandwashwithsoap

andwater.Washordiscardclothingandrags

contaminatedwithengineuids.

3.Placeadrainpanundertheoilpandrainplug,removeoil

pandrainplug,anddrainoil.

Page67
