SECTION5–MAINTENANCESCHEDULEANDSERVICEPROCEDURES
4.DiscardoilpandrainplugO-ring.Inspecttheoilpandrain
plug.Ifitisfreeofdefects,itcanbereused.Replaceif
necessary.
5.Usingcleanengineoil,lubricateanewoilpandrainplug
O-ring.PutO-ringontotheoilpandrainplug.
6.Installoilpandrainplugandtightento68N·m(50lbf·ft).
7.Recycleordisposeofoilaccordingtoapplicableregulations.
Figure31Oilcoolermoduleassembly
1.Oilcoolerhousing
2.Oilcooler
3.Oillter
8.Putdrainpanunderoillter.
9.Removeoldoillterandrecycleordisposeofaccordingto
applicableregulations.
10.Lubricatenewoilltergasketwithcleanengineoil.
CAUTION
Topreventenginedamage,installthecorrectoil
lterfortheengineapplication.
11.Installnewoillter.
•Standardoillter(long)
•Frontdrive/steeringaxleoillter(shorter)
CAUTION
Topreventenginedamage,donotovertighten
lter.
12.Handtightenlter2/3to1fullturnaftergasketrstcontacts
oillterheader.
CAUTION
Topreventenginedamage,donotoverllwithoil.
13.Addengineoilwiththecorrectoilviscosityandformulation.
APICJ-4oilisrecommendedbutCI-4isallowable.Useof
CI-4oilswillreduceDPFcleaninginterval,seeMaintenance
Schedule(page57).Addoilthroughtheengineoillltube.
Page68
