V16 PRINT CONNECTIONS
Main Print Board 12 pin cable WIRE INPUTS OUTPUTS NUMBER FUNCTION
100V-240V PE-N-L 1-2-3 100-240 Volt 50-60Hz
THERM C-C2 7-8-9 Safety Thermostat
MOTOR PE-N-L1 4-5-6 External Auger
BURNER Green/Yelllow GND 10
BURNER WHITE N 11
BURNER YELLOW L2 12 Blower
BURNER GREEN L3 13 Internal auger
BURNER BLUE L4 14 Igniter
EXTRA 1 PE-N-L5 15-16-17 Circulation Pump
EXTRA 1 RED L6 18 Compressor Cleaning Burner
EXTRA 2 PE-N-L7 19-20-21 Ash Auger
EXTRA 2 PE-N-L8 19-20-22 Compressor
EXTRA 3 PE-N-L9 23-24-25 Compressor Boiler Valve 1
EXTRA 3 PE-N-L10 23-24-26 Compressor Boiler Valve 2
EXTRA 4 PE-N-L11 27-28-29 Exhaust Fan
EXTRA 4 PE-N-L12 Available Output for Accessories.
EXTRA 4 PE-N-L13 Available Output for Accessories.
EXTRA 5 PE-N-L14 Available Output for Accessories.
EXTRA 5 PE-N-L15 Available Output for Accessories.
EXTRA 5 PE-N-L16 Available Output for Accessories.
BUS 1 GRD 70
Available for Extension Module* BUS 1 RX 71
BUS 1 TX 72
AIRFLOW 3V Free
AIRFLOW TX Free
AIRFLOW PINK RX 50 Air Flow Sensor Burner
PRESSURE BROWN 3V 52
Compressor Pressure Sensor
PRESSURE BLACK SIG 53
PRESSURE 0V 54
DISTANCE BLACK - 57
Lazer Distance Sensor for Hopper DISTANCE YELLOW SIG 56
DISTANCE RED + 55
O2 SENSOR BLACK Black 69
O2 Sensor
O2 SENSOR BLACK Black 70
O2 SENSOR WHITE Gray 71
O2 SENSOR BLUE Blue 72
POWER OUT PE-N-L 66-67-68 Power Supply to Ext Module/ DHW Priority Kit
CONTACT K-K1 67-68 External Contact ON/OFF*
PULS P-P1 Free
PULS P-P2 Free
PULS P-P3 Free
PULS P-P4 Free
DISTANCE RED + 55
Ash Can Level Sensor DISTANCE BLACK - 57
BP YELLOW BP 69
TEMP. T- T1 41-40 Boiler Temperatue Sensor
TEMP. T – T2 41-42 Chimney Temperature Sensor
TEMP. T – T3 44-43 Free/ Return Temperature Sensor*
TEMP. T – T4 44-45 Free/DHW Temperature Sensor *
TEMP. T – T5 Free
TEMP. T – T6 Free
SHAFT. / TEMP BLACK T – T9 37 Drop Shaft Sensor Burner
SHAFT. / TEMP ORANGE T 38 Motorprint
SHAFT/ TEMP T-T10 39 Free
*REQUIRES ACCESSORY
PE= YELLOW/GREEN N= BLUE L = BROWN
