NBE RTB PHOENIX v16.0 - INSTALLING CERAMIC HEATING ELEMENT 300 W.; Recommended Adjustments

There must be a minimum of 3 mm air around the heating element
The ceramic heating element must not be in contact with any metal surface
INSTALLING CERAMIC
HEATING ELEMENT300 W.
Recommended adjustments:
• Preheating 30 sek.
• Power 65 %
• Max time 6 min.
• Blower low 40 %
• Blower middle 50 %
• Blower high 60 %
39
12 pin BURNER PRINT WIRE INPUTS OUTPUTS FUNCTION SKU:
IGNTION BLUE N
Igniter
Ceramic heating element 250Watt, SKU :
400305
IGNITION BROWN L1
