NCR Blk7 - Installing the Cash Drawer

36 7603-K507 Peripheral Integration, Blk7, XR6
Installing the Cash Drawer
The Cash Drawer can be installed remotely or integrated with the terminal. The Cash
Drawer Cable is then connected to the Cash Drawer connector on the terminal.
Note: The NCR 2181 Cash Drawer, with its smaller footprint, is required for the
integrated configuration.
31279
Remote Configuration
Integrated Configuration
Note: The images above show a different PeripheralIntegration Kit, but the concept is
still the same.
