NCR Blk7 - Installation Procedures

4 7603-K507 Peripheral Integration, Blk7, XR6
Installation Procedures
Installing and using the Peripheral Integration kit involves the following procedures:
1. Assemble the Integration kit. For more information, refer to Assembling the Integration
Kit on the facing page.
2. Install the XR6terminal into the Integration Chassis. For more information, refer to
Installing the Terminal on page8
3. Install the Bezel. For more information, refer to Installing the Bezel on page11
4. Install the peripherals into the Integration Tray. For more information, refer to
Installing Peripherals on page12
5. Install the Cash Drawer. For more information, refer to Installing the Cash Drawer on
page36
6. Install the Swing Arm Skirts. For more information, refer to Installing the Swing Arm
Skirts on page39
7. Install the CableCover. For more information, refer to Installing the CableCover on
page41.
