4 RealPOS XR7 Integration Tray Kit Instructions
Installing on a Counter Top
1. Position the Tray Support Bracket on the counter top and secure it with screws (4)
that are appropriate for the surface type.
Note: The mounting holes for the 3rd-party mount much be located toward the
rear of the unit.
2. Position the Integration Tray on top of the Tray Support Bracket. Secure the tray to
the Tray Support Bracket with screws (2). Secure the front of the tray to the counter
top with screws (2) that are appropriate for the surface type
