NEC NP-P451X Installation And Assembly Manual

ISSUED: 10-01-10 SHEET #: 056-9034-4 07-29-11
Visit the Peerless Web Site at www.peerlessmounts.com
5 of 10
For customer care call 1-800-865-2112
Placeprojectormountassembly(A)onceilingasatemplateandmarkthecenterofthetwomountingholes.
Makesurethatthemountingholesareinthecenterofthewoodjoist.Drilltwo5/32"(4mm)dia.holestoa
minimumdepthof2.5"(64mm).Attachprojectormountassembly(A)withtwo#14x2.5"woodscrews(F)and
twoatwashers(E)asshowningure 2.1orgure 2.2dependingonjoistorientation.
NOTE: Mountingslotsonprojectormountassemblyallowfor30°(±15°)ofswiveladjustmentbeforefullysecuring
woodscrews.
Tightenwoodscrews(F)using3/8"(10mm)socketwrench,phillipsscrewdriveror10mmopenendwrenchuntil
projectormountassembly(A)isrmlyattached.
Skip to step 5.
Installation To Wood Joist Ceilings
2
• Installermustverifythatthesupportingsurfacewillsafelysupportthecombinedloadoftheequipmentandall
attachedhardwareandcomponents.
• Tightenwoodscrewssothatprojectormountassemblyisrmlyattached,butdonotovertighten.Overtightening
candamagethescrews,greatlyreducingtheirholdingpower.
• Nevertighteninexcessof80in.•lb(9N.M.).
• Makesurethatmountingscrewsareanchoredintothecenterofthestud.Theuseofan"edgetoedge"studnder
ishighlyrecommended.
• Hardwareprovidedisforattachmentofmountthroughstandardthicknessdrywallorplasterintowoodstuds.
Installersareresponsibletoprovidehardwareforothertypesofmountingsituations(notevaluatedbyUL).
WARNING
F
F
A
WOODJOIST
FRONTOF
MOUNT
E
E
WOODJOIST
A
ACCESSSLOTFOR
OPENENDWRENCH
ALLOWSTIGHTENING
OFWOODSCREW
g. 2.1
g. 2.2
ARROWONTOPOF
PROJECTORMOUNT
ASSEMBLYINDICATES
FRONTOFMOUNT
