NEC NP-P451X Installation And Assembly Manual

ISSUED: 10-01-10 SHEET #: 056-9034-4 07-29-11
Visit the Peerless Web Site at www.peerlessmounts.com
8 of 10
For customer care call 1-800-865-2112
Alignshoulderonconnectionblock(EE)opposite
notchinadapterplate(AA).Attachadapterplate
(AA)toconnectionblock(EE)usingtwo#10-32x
3/8"serratedwasherheadsocketpinscrews(C)
asshowningure5.1.Tightenscrewsusing4mm
allenwrench(B).
C
NOTCHINDICATES
FRONTOFPROJECTOR
SHOULDER
Attaching Adapter Plate to Projector
g. 5.1
BB
Flipprojectorupsidedownandattachadapterplate(AA)usingfourserratedsocketpinscrews(BB)andretaining
spacers(CC)asshownbelow.Tightenusing4mmallenwrench(B).
NOTE:Retainingspacers(CC)gobetweentheprojectorandadapterplate(AA).
AA
CC
AA
EE
5
6
