NEC NP-P451X Installation And Assembly Manual

ISSUED: 10-01-10 SHEET #: 056-9034-4 07-29-11
Visit the Peerless Web Site at www.peerlessmounts.com
9 of 10
For customer care call 1-800-865-2112
Slideconnectionblock(EE)withprojectorintoprojectormountassembly(A)asshown.Tightencaptivescrewto
secureprojectortoprojectormountassembly(A).
IMPORTANT:Forsecurityinstallations,insertone#10-32x1/4"socketpinscrew(D)throughprojectormount
assembly(A)andintoconnectionblock(EE)asshownindetail1.Tightenscrewusing4mmsecurityallen
wrench(B).
A
D
• Donotliftmoreweightthanyoucanhandle.Useadditionalmanpowerormechanicalliftingequipmenttosafely
handleplacementofthescreen.
WARNING
Attaching Adapter Plate to Projector Mount
DETAIL 1
EE
7
8
A
FRONTOFMOUNT
CAPTIVESCREW
ARROWINDICATES
FRONTOFMOUNT
EE
